Our client has been tasked with replacing and retrofitting new food processing plant equipment at a large manufacturing facility. The existing plant in-situ is old and poorly documented in respect to the as-built position on the manufacturing floor. The accurate XYZ position of the plant is important to our client. Much of the new equipment […]

The Huia Water Treatment Plant, opened 1928, is to undergo significant redevelopment. The original building and water works are to be retained and hold heritage status. Our client requires a digital record of the front façade of the building together with the original settling tanks in front of the building. The Cheal scanning team used […]

Cheal owns a Creaform metrology grade scanner. This handheld scanning device is submillimetre accurate and capable of digitising the finest of detail found in artwork. Should the artwork require documenting for insurance purposes or simply to be captured in digital format for input to a 3D printer, our experienced Cheal scanning team are able to […]

The Palmerston North Cathedral does not meet current seismic building code compliance and is therefore earmarked for strengthening remedial works. In order to ascertain the current structural status of the building without having adequate drawing documentation available a 3D model of the building is called for. The Cheal scanning team are engaged by a UAV […]

Our client engaged Cheal Surveyors to 3D capture their Hydro Station facilities at three locations being Keepit, Hume and Burrinjuck within the state of New South Wales. The client’s requirement was to capture the entire exterior and interior of each of the facilities and deliver a 3D CAD solid model to import to SolidWorks software. […]

Cheal was engaged by our client to scan heritage building facades in the town of Marton. The buildings are of significant heritage value to the town. The facades were captured with our 3D laser scanner from various locations and the data processed with high quality imaging software. The captured data is used to prepare elevation […]
